Cutler Hammer GD3100D

Cutler Hammer GD3100D

circuit breakers

  • Catalog Number: GD3100D
  • Manufacturer: Cutler Hammer
  • Connection: Bolt-on
  • Frame Type: GD
  • Amperage: 100
  • Poles: 3
  • Voltage: 480

Cutler...

More Info
$232.00
$270.00
$232.00
  • Category: Buy Wholesale Circuit Breakers | Top Brands & Manufacturers, Eaton Cutler Hammer Circuit Breakers, New Circuit Breakers, Used Circuit Breakers
  • Catalog Number: GD3100D
  • Manufacturer: Cutler Hammer
  • Connection: Bolt-on
  • Frame Type: GD
  • Amperage: 100
  • Poles: 3
  • Voltage: 480

Cutler Hammer GD3100D Specifications:


  • THERMAL MAGNETIC
  • G FRAME
  • 480 VAC AT 50/60 HZ, 250 VDC
  • 100 AMPERE AT 40 DEG C
  • 3 POLE
  • INTERRUPTING RATING 65 KILOAMPERE AT 240 VAC, 22 KILOAMPERE AT 480 VAC, 10 KILOAMPERE AT 250 VDC (UL)



Cutler Hammer GD3100D Details:


  • Commodity Description: Circuit Breakers - Commercial Circuit Breakers
  • Type: THERMAL MAGNETIC
  • Current Rating: 100 AMPERE AT 40 DEG C
  • Interrupting Rating: 65 KILOAMPERE AT 240 VAC, 22 KILOAMPERE AT 480 VAC, 10 KILOAMPERE AT 250 VDC (UL)
  • Terminal Type: SCREW TYPE PRESSURE LINE TERMINAL, SCREW TYPE PRESSURE LOAD TERMINAL
In addition to a detailed inspection, every Circuit Breaker Wholesale product comes with a comprehensive warranty covering defects for 1 year. Reconditioned products come with a comprehensive warranty covering defects for 3 years. Circuit Breaker Wholesale will repair, replace or service all covered components, that are found to be defective in factory-supplied products during the applicable warranty periods. All warranty items must be returned to Circuit Breaker Wholesale for a full inspection and must be returned within the warranty period. Contact us at support@circuitbreakerwholesale.com or call us at (800) 800-800 for help with your warranty claim.
