Siemens / ITE CQD290

Siemens / ITE CQD290

circuit breakers

  • Manufacturer: Siemens / ITE
  • Current Condition:
  • Type: CQD
  • Amperage: 90
  • Poles: 2
  • Voltage: 277/480

Siemens / ITE CQD290 Specifications:


  • THERMAL MAGNETIC
  • 2...
More Info
$151.00
$151.00
  • Category: ITE Circuit Breakers, New ITE Circuit Breakers, Used ITE Circuit Breakers
  • Manufacturer: Siemens / ITE
  • Current Condition:
  • Type: CQD
  • Amperage: 90
  • Poles: 2
  • Voltage: 277/480

Siemens / ITE CQD290 Specifications:


  • THERMAL MAGNETIC
  • 2 POLE
  • 480 STAR/277 VAC AT 50/60 HZ
  • 125/250 VDC
  • 90 AMPERE AT 40 DEG C
  • INTERRUPTING RATING 65 KILOAMPERE AT 240 VAC
  • 14 KILOAMPERE AT 480 STAR/277 VAC/250 VDC (UL)
  • LUG TERMINAL
  • WIRE SIZE 6 TO 1/0 AWG ALUMINUM
  • 8 TO 1 AWG COPPER
  • CABLE IN
  • CABLE OUT
  • DIN RAIL MOUNTING
  • SIZE 2 INCH W X 2.88 INCH D X 4.87 INCH H
  • APPROVAL UL 489
  • CSA 22.2
  • SENTRON[R] BRAND
  • CQD MODEL Molded Case Circuit Breakers from Siemens / ITE



Siemens / ITE CQD290 Details:


  • BREAKER CQD 2P 90A 480/277V 14KA DIN (More Details)
In addition to a detailed inspection, every Circuit Breaker Wholesale product comes with a comprehensive warranty covering defects for 1 year. Reconditioned products come with a comprehensive warranty covering defects for 3 years. Circuit Breaker Wholesale will repair, replace or service all covered components, that are found to be defective in factory-supplied products during the applicable warranty periods. All warranty items must be returned to Circuit Breaker Wholesale for a full inspection and must be returned within the warranty period. Contact us at support@circuitbreakerwholesale.com or call us at (800) 800-800 for help with your warranty claim.
