Siemens / ITE NEB3B110B

Siemens / ITE NEB3B110B

circuit breakers

  • Manufacturer: Siemens / ITE
  • Current Condition:
  • Type: NEB
  • Amperage: 110
  • Poles: 3
  • Voltage: 480
  • Short Circ Int Cap: 35kA

Siemens / ITE NEB3B110B Specifications:

...
More Info
$666.00
$666.00
  • Category: ITE Circuit Breakers, New ITE Circuit Breakers, Used ITE Circuit Breakers
  • Manufacturer: Siemens / ITE
  • Current Condition:
  • Type: NEB
  • Amperage: 110
  • Poles: 3
  • Voltage: 480
  • Short Circ Int Cap: 35kA

Siemens / ITE NEB3B110B Specifications:


  • 240/480 VAC
  • 600 VAC STAR/347 VAC AT 50/60 HZ
  • 125/250 VDC (UL/CSA)
  • 240/415 VAC AT 50/60 HZ
  • 125/250 VDC (IEC)
  • 110 AMPERE
  • 3 POLE
  • INTERRUPTING RATING 85 KILOAMPERE AT 240 VAC
  • 35 KILOAMPERE AT 480 VAC
  • 22 KILOAMPERE AT 600 VAC STAR/347 VAC
  • 35 KILOAMPERE 125/250 VDC (UL/CSA)
  • 85 KILOAMPERE AT 240 VAC
  • 40 KILOAMPERE AT 415 VAC
  • 35 KILOAMPERE AT 125/250 VDC (IEC)
  • USED ON NEB PANELBOARD
  • TERMINAL TYPE LOAD LUG Molded Case Circuit Breakers from Siemens / ITE



Siemens / ITE NEB3B110B Details:


  • BREAKER NEB 3P 110A 480V 35KA LOAD LUGS (More Details)
In addition to a detailed inspection, every Circuit Breaker Wholesale product comes with a comprehensive warranty covering defects for 1 year. Reconditioned products come with a comprehensive warranty covering defects for 3 years. Circuit Breaker Wholesale will repair, replace or service all covered components, that are found to be defective in factory-supplied products during the applicable warranty periods. All warranty items must be returned to Circuit Breaker Wholesale for a full inspection and must be returned within the warranty period. Contact us at support@circuitbreakerwholesale.com or call us at (800) 800-800 for help with your warranty claim.
