Siemens / ITE NGB2B020B

Siemens / ITE NGB2B020B

circuit breakers

  • Manufacturer: Siemens / ITE
  • Current Condition:
  • Type: NGB
  • Amperage: 20
  • Poles: 2
  • Voltage: 600

Siemens / ITE NGB2B020B Specifications:


  • 240 VAC AT 50/60HZ
  • ...
More Info
$172.00
$172.00
$188.00
  • Category: ITE Circuit Breakers, New ITE Circuit Breakers, Used ITE Circuit Breakers
  • Manufacturer: Siemens / ITE
  • Current Condition:
  • Type: NGB
  • Amperage: 20
  • Poles: 2
  • Voltage: 600

Siemens / ITE NGB2B020B Specifications:


  • 240 VAC AT 50/60HZ
  • 480 VAC STAR/277 VAC AT 50/60HZ
  • 600 VAC STAR/347 VAC AT 50/60HZ
  • 125/250 VDC (UL)
  • 240/415 VAC AT 50/60HZ
  • 125/250 (IEC)
  • 20 AMPERE
  • 2 POLE
  • INTERRUPTING RATING 100 KILOAMPERE AT 240 VAC
  • 25 KILOAMPERE AT 480 VAC STAR/277 VAC
  • 14 KILOAMPERE AT 600 VAC STAR/347 VAC
  • 14 KILOAMPERE AT 125/250 VDC (UL)
  • 65 KILOAMPERE AT 240 VAC
  • 25 KILOAMPERE AT 415 VAC
  • 14 KILOAMPERE AT 125/250 VDC (IEC)
  • USED ON NGB 125A PANELBOARD
  • NGB MODEL Molded Case Circuit Breakers from Siemens / ITE



Siemens / ITE NGB2B020B Details:


  • BREAKER NGB 2P 20A 600V 14KA LD LUG (More Details)
In addition to a detailed inspection, every Circuit Breaker Wholesale product comes with a comprehensive warranty covering defects for 1 year. Reconditioned products come with a comprehensive warranty covering defects for 3 years. Circuit Breaker Wholesale will repair, replace or service all covered components, that are found to be defective in factory-supplied products during the applicable warranty periods. All warranty items must be returned to Circuit Breaker Wholesale for a full inspection and must be returned within the warranty period. Contact us at support@circuitbreakerwholesale.com or call us at (800) 800-800 for help with your warranty claim.
