Siemens / ITE NGB2B125

Siemens / ITE NGB2B125

circuit breakers

  • Manufacturer: Siemens / ITE
  • Current Condition:

Siemens / ITE NGB2B125 Specifications:


  • 240/480 VAC
  • 600 VAC STAR/347 VAC AT 50/60 HZ
  • 250...
More Info
$444.00
$485.00
$444.00
  • Category: ITE Circuit Breakers, New ITE Circuit Breakers, Used ITE Circuit Breakers
  • Manufacturer: Siemens / ITE
  • Current Condition:

Siemens / ITE NGB2B125 Specifications:


  • 240/480 VAC
  • 600 VAC STAR/347 VAC AT 50/60 HZ
  • 250 VDC (UL)
  • 220/240/380/415 VAC AT 50/60 HZ
  • 250 VDC (IEC)
  • 125 AMPERE
  • 2 POLE
  • INTERRUPTING RATING 65 KILOAMPERE AT 240 VAC
  • 25 KILOAMPERE AT 480 VAC
  • 18 KILOAMPERE AT 600 VAC STAR/347 VAC
  • 14 KILOAMPERE AT 250 VDC (UL)
  • 25 KILOAMPERE AT 220/240/380/415 VAC
  • 10 KILOAMPERE AT 250 VDC (IEC)
  • USED ON NGB PANELBOARD
  • SIZE 2 INCH W X 3.3 INCH D X 5.4 INCH H Molded Case Circuit Breakers from Siemens / ITE



Siemens / ITE NGB2B125 Details:


  • BREAKER NGB 2P 125A 600V 14KA NO LUGS (More Details)
In addition to a detailed inspection, every Circuit Breaker Wholesale product comes with a comprehensive warranty covering defects for 1 year. Reconditioned products come with a comprehensive warranty covering defects for 3 years. Circuit Breaker Wholesale will repair, replace or service all covered components, that are found to be defective in factory-supplied products during the applicable warranty periods. All warranty items must be returned to Circuit Breaker Wholesale for a full inspection and must be returned within the warranty period. Contact us at support@circuitbreakerwholesale.com or call us at (800) 800-800 for help with your warranty claim.
