Siemens / ITE NJG3B350

Siemens / ITE NJG3B350

circuit breakers

  • Manufacturer: Siemens / ITE
  • Current Condition:
  • Type: NJGA
  • Amperage: 350
  • Poles: 3
  • Voltage: 690

Siemens / ITE NJG3B350 Specifications:


  • THERMAL MAGNETIC
  • MOLDED...
More Info
  • Category: ITE Circuit Breakers, New ITE Circuit Breakers, Used ITE Circuit Breakers
  • Manufacturer: Siemens / ITE
  • Current Condition:
  • Type: NJGA
  • Amperage: 350
  • Poles: 3
  • Voltage: 690

Siemens / ITE NJG3B350 Specifications:


  • THERMAL MAGNETIC
  • MOLDED CASE
  • JG FRAME
  • 240/480/600 VAC AT 50/60 HZ
  • 500 VDC (UL)
  • 220/240/380/415/690 AT 50/60 HZ (IEC)
  • 350 AMPERE
  • 3 POLE
  • INTERRUPTING RATING 65 KILOAMPERE AT 240 VAC
  • 35 KILOAMPERE AT 480 VAC
  • 25 KILOAMPERE AT 600 VAC
  • 25 KILOAMPERE AT 500 VDC (UL)
  • 65 KILOAMPERE AT 220/240 VAC
  • 45 KILOAMPERE AT 380/415 VAC
  • 12 KILOAMPERE AT 690 VAC (IEC)
  • SIZE 5.5 INCH W X 5.4 INCH D X 11 INCH H
  • APPROVAL UL
  • CSA
  • CE
  • NOM Molded Case Circuit Breakers from Siemens / ITE



Siemens / ITE NJG3B350 Details:


  • 350A 600V 35K THERMAL MAGNETIC CIRCUIT BREAKER (More Details)
