Siemens MTG3000A

Siemens MTG3000A

motor control

  • Catalog Number: MTG3000A
  • Manufacturer: Siemens

Siemens MTG3000A Specifications:


  • PRIMARY VOLTAGE 220 X 440 V, 230 X 460 V, 240 X 480 V
  • ...
More Info
  • Category: Motor Controls, New Motor Controls, Siemens Motor Control, Used Motor Controls
  • Catalog Number: MTG3000A
  • Manufacturer: Siemens

Siemens MTG3000A Specifications:


  • PRIMARY VOLTAGE 220 X 440 V, 230 X 460 V, 240 X 480 V
  • SECONDARY VOLTAGE 110 V, 115 V, 120 V
  • 50/60 HZ
  • POWER RATING 3000 VA
  • SCREW TERMINAL
  • TEMPERATURE RISE 55 DEG C
  • 3/4 INCH L X 7/16 INCH W SLOT MOUNTING
  • SIZE 9 INCH W X 6.25 INCH D X 9.38 INCH H



Siemens MTG3000A Details:


  • Directory:: CIS
  • Commerce Sector:: Construction Materials
  • Industry:: Electrical
  • Commodity Code:: 3920
  • Commodity Description:: Power Transformers, etc. - Control Transformers
  • :
  • UPC:: 75455452048
  • Item Number:: 52048
  • Catalog Number:: MTG3000A
  • :
  • UNSPSC:: 39121000
  • :
  • Model:: MTG
  • Primary Voltage:: 220 X 440 V, 230 X 460 V, 240 X 480 V
  • Secondary Voltage:: 110 V, 115 V, 120 V
  • Frequency Rating:: 50/60 HZ
  • Power Rating:: 3000 VA
  • Power Rating in VA:: 3000
  • Power Rating in VA - UOM:: VA
  • Terminal Type:: SCREW
  • Temperature Rise:: 55 DEG C
  • Mounting:: 3/4 INCH L X 7/16 INCH W SLOT
  • Size:: 9 INCH W X 6.25 INCH D X 9.38 INCH H
  • Applicable Standard:: ANSI, NEMA
  • Approval:: UL, CSA, CE
  • Additional Information:: OUTPUT CURRENT 26.09 AMPERE
In addition to a detailed inspection, every Circuit Breaker Wholesale product comes with a comprehensive warranty covering defects for 1 year. Reconditioned products come with a comprehensive warranty covering defects for 3 years. Circuit Breaker Wholesale will repair, replace or service all covered components, that are found to be defective in factory-supplied products during the applicable warranty periods. All warranty items must be returned to Circuit Breaker Wholesale for a full inspection and must be returned within the warranty period. Contact us at support@circuitbreakerwholesale.com or call us at (800) 800-800 for help with your warranty claim.
