Square D 781R122

Square D 781R122

motor control

  • Catalog Number: 781R122
  • Manufacturer: Square D

Square D 781R122 Specifications:


  • WINDOW TYPE
  • CURRENT RATIO 1200:5
  • 600 V
  • ACCURACY 0.3...
More Info
  • Category: Motor Controls, New Motor Controls, Square D Motor Control, Used Motor Controls
  • Catalog Number: 781R122
  • Manufacturer: Square D

Square D 781R122 Specifications:


  • WINDOW TYPE
  • CURRENT RATIO 1200:5
  • 600 V
  • ACCURACY 0.3 (B0.1/B0.2/B0.5/B0.9/B1.8)
  • BURDEN B0.1/B0.2/B0.5/B0.9/B1.8
  • RATING FACTOR 2
  • WINDOW SIZE 6-1/2 INCH DIA
  • SQUARE HOUSING
  • 781R MODEL



Square D 781R122 Details:


  • Directory:: CIS
  • Commerce Sector:: Construction Materials
  • Industry:: Electrical
  • Commodity Code:: 3930
  • Commodity Description:: Power Transformers, etc. - Current Transformers
  • UPC:: 78590128602
  • Item Number:: 28602
  • Catalog Number:: 781R122
  • UNSPSC:: 39121003
  • Model:: 781R
  • Type:: WINDOW TYPE
  • Current Ratio:: 1200
  • Voltage Rating:: 600 V
  • Accuracy:: 0.3 (B0.1/B0.2/B0.5/B0.9/B1.8)
  • Burden:: B0.1/B0.2/B0.5/B0.9/B1.8
  • Rating Factor:: 2
  • Window Size:: 6-1/2 INCH DIA
  • Housing Shape:: SQUARE
