Square D LBA362101

Square D LBA362101

motor control

  • Catalog Number: LBA362101
  • Manufacturer: Square D

Square D LBA362101 Specifications:


  • STANDARD
  • 600 V
  • 3 POLE
  • 1 PRIMARY OPENINGS PER...
More Info
  • Category: Motor Controls, New Motor Controls, Square D Motor Control, Used Motor Controls
  • Catalog Number: LBA362101
  • Manufacturer: Square D

Square D LBA362101 Specifications:


  • STANDARD
  • 600 V
  • 3 POLE
  • 1 PRIMARY OPENINGS PER POLE
  • 14 TO 2/0 AWG PRIMARY OPENING WIRE SIZE
  • 1 SECONDARY OPENINGS PER POLE
  • 14 TO 2/0 AWG SECONDARY OPENING WIRE SIZE
  • CONDUCTOR MATERIAL ALUMINUM/COPPER
  • LB23, CLEAR PLASTIC COVER



Square D LBA362101 Details:


  • Directory:: CIS
  • Commerce Sector:: Construction Materials
  • Industry:: Electrical
  • Commodity Code:: 3400
  • Commodity Description:: Distribution Equipt - Panelboards & Switchboards
  • UPC:: 78590115070
  • Item Number:: 15070
  • Catalog Number:: LBA362101
  • UNSPSC:: 39121410
  • Model:: LB
  • Type:: STANDARD
  • Voltage Rating:: 600 V
  • Number of Poles:: 3
  • Number of Primary Openings per Pole:: 1
  • Primary Opening Wire Size:: 14 TO 2/0 AWG
  • Number of Secondary Openings per Pole:: 1
  • Secondary Opening Wire Size:: 14 TO 2/0 AWG
  • Conductor Material:: ALUMINUM/COPPER
  • Cover Type:: LB23, CLEAR PLASTIC
  • Temperature Rating:: -40 TO 150 DEG C
  • Connector Material:: TIN PLATED ALUMINUM
  • Housing Material:: PHENOLIC
  • Size:: 2.75 INCH L X 2.88 INCH W X 1.78 INCH H
  • Approval:: UL, CSA
  • Additional Information:: APPLICABLE STANDARD NEC 310-16
In addition to a detailed inspection, every Circuit Breaker Wholesale product comes with a comprehensive warranty covering defects for 1 year. Reconditioned products come with a comprehensive warranty covering defects for 3 years. Circuit Breaker Wholesale will repair, replace or service all covered components, that are found to be defective in factory-supplied products during the applicable warranty periods. All warranty items must be returned to Circuit Breaker Wholesale for a full inspection and must be returned within the warranty period. Contact us at support@circuitbreakerwholesale.com or call us at (800) 800-800 for help with your warranty claim.
